IRD-2600 / IRD-2800
Integrated Receiver Decoders
P/N 2349-72784-00 Page 3-7
3.2.1. Configuration / Receiver Menu
The IRD is provided in a wide range of input receivers: QPSK (DVB-S), DSNG
(DVB-DSNG), QAM (DVB-C), G.703 (E1, E2, E3) and ATM (DVB-PDH, SDH)) receiver
options. The Configuration / Receiver Menu is input sensitive (i.e., varies automatically
according to the IRD Input option installed), and provides a group of functions to configure
the receiver section of the IRD.
Figure 3-5 shows the various menu options provided for the different front-end interfaces.
NOTE
IRD with a G.703 Input type receiver is automatically configured, thus no
configuration functions under the Configuration/Receiver Menu are applicable
for this option.
The IRD Front Panel display, controls and keypad are used to scroll through the menu,
view the options available and set the parameters of the configuration functions provided.
Table 3-4 describes the configuration functions available for the receiver option installed in
the IRD-2600 / IRD-2800 (DSNG, QPSK, QAM. ATM and G.703 input options).
The ; icon legend is used to show menu option availability for the different input receiver:
