IRD-2600 / IRD-2800
Integrated Receiver Decoders
P/N 2349-72784-00 Page 1-15
1.4. Management
The IRD-2600 and IRD-2800 Integrated Receiver Decoder contain embedded software for
control and configuration. The embedded software is accessible by the following interfaces:
• IRD-2600/IRD-2800 Front Panel
• Infrared Remote Control
• PC terminal
• NMS-4000 broadcast link via an external modem
In addition to the embedded software, prepared program scripts may be applied to the
IRD-2600 and IRD-2800 via a PC terminal, or via the NMS-4000.
1.4.1. Front Panel Control
The IRD-2600 and IRD-2800 Front Panel provide a two line LCD display and a control keys.
It enables the user to control and monitor the IRD-2600 and IRD-2800.
1.4.2. Infrared Remote Control
The infrared remote control device optionally supplied with the IRD-2600 and IRD-2800
enables arm chair control of the IRD-2600 and IRD-2800. The control keys are similar to
those on the IRD-2600 and IRD-2800 Front Panel in order to provide a common interface and
control syntax.
1.4.3. PC Terminal Control
The IRD-2600 and IRD-2800 may be controlled and configured from a standard PC terminal
attached to the Control (RS-232 or RS-485) connector. The terminal provides access to
control and monitor functions not available when using the IRD-2600 and IRD-2800 Front
Panel or the infrared remote control.
1.4.4. NMS-4000 Control
The CODICO
®
NMS-4000 Network Management System enables management of the
IRD-2600 and IRD-2800 via the Transmission Link.
The NMS-4000 provides a menu and dialog-driven interface from which control, modification,
and upgrade operations can be performed on the IRD-2600 and IRD-2800.
