IRD-2600 / IRD-2800
Integrated Receiver Decoders
P/N 2349-72784-00 Page 1
Appendix A. Operational Menu Trees
The Operational Menus provided on the front panel of CODICO
®
IRD-2600 and IRD-2800
Integrated Receiver Decoders enables the operator to control, configure and monitor the
operation of the IRD according to the parameters required by the particular DVB System.
Navigation in the operational trees requires prior knowledge of the main menu structure
and the options available in each menu of a particular unit. Chapter 3, Operation provides
all the information required to use the extended operational menu tree.
This appendix provides quick and full diagrams of the operational menu trees for the
various IRD configurations available:
• DSNG Configuration (see Figure A-1).
• QPSK Configuration (see Figure A-2).
• QAM Configuration (see Figure A-3).
• G.703 Configuration (see Figure A-4).
• ATM (DVB-PDH) Configuration (see Figure A-5).
All configurations share a common initialization phase and Main Menu structure, as
described in paragraph 3.1.1.3. Common Status Messages will also be displayed on the
LCD in case of hardware failure or general-purpose information. For a description of the
Status Messages, please refer to paragraph 4.4.
A dotted menu selection in the diagrams indicates that the availability of this option is
dependent upon the system configuration. For example, Password control is available as
an option for the IRD. Once a session has been initiated via the Password, the password is
bypassed on repeated entry to the MAIN MENU.
NOTE
Unless specifically marked, all items are applicable for both the IRD-2600 and
the IRD-2800.
Items marked by double asterix (**) are available ONLY for IRD-2600.
Items marked by a hart triple asterix (***) are available ONLY for IRD-2800.
