User Manual
Chapter 3. Operation
Page 3-34 P/N 2349-72784-00
Table 3-10: Receiver Status Menu Parameters
DSNG
Q
P
S
K
QAM
ATM
G.703
OPTION DESCRIPTION
;
ATM Bit
CAUTION
Advanced status functions to be operated ONLY by the
authorized Scopus personnel. Unauthorized operation may
create in unpredicted results.
;
ATM Input Rate
ATM IRD Input Modulation
Displays the input rate active at the ATM IRD receiver (as set
in the Receiver Configuration Menu, see paragraph 3.2.1).
Options available: 14 Kbit/sec.
3.3.2. Status / Decoder Menu
The Decoder Status Menu enables the IRD user to monitor the status of the decoder in the
IRD. Figure 3-14 shows the menu tree of status parameters available in the Decoder
Status Menu (password is required only if it was enabled previously).
The IRD Front Panel display, controls and keypad are used to scroll through the menu,
view the options available and set the parameters of the configuration functions provided.
The Decoder Status monitoring options are grouped into four groups and are described in
the following sub-paragraphs:
• Decoder/Stream Status monitoring sub-menu, refer to paragraph 3.3.2.1.
• Decoder/Common Interface (CI) Status monitoring sub-menu, refer to paragraph
3.3.2.2.
• Decoder/Video Status monitoring sub-menu, refer to paragraph 3.3.2.3.
• Decoder/Audio Status monitoring sub-menu, refer to paragraph 3.3.2.4.
