User Manual
Chapter 3. Operation
Page 3-14 P/N 2349-72784-00
3.2.2. Configuration / Decoder Menu
The Decoder Configuration menu provides the IRD user the capability to setup and
configure the decoder in the IRD. Figure 3-6 shows the menu tree of configuration
functions available in the Decoder Configuration Menu (password is required only if it was
enabled previously).
The IRD Front Panel display, controls and keypad are used to scroll through the menu,
view the options available and set the parameters of the configuration functions provided.
The Decoder Configuration functions are grouped into four groups and are described in the
following sub-paragraphs:
• Decoder/Stream functions configuration sub-menu, refer to paragraph 3.2.2.1.
• Decoder/Common Interface (CI) functions configuration sub-menu, refer to paragraph
3.2.2.2.
• Decoder/Video functions configuration sub-menu, refer to paragraph 3.2.2.3.
• Decoder/Audio functions configuration sub-menu, refer to paragraph 3.2.2.4.
