3.3.2.2. Decoder / CI Status Sub-Menu
The Decoder / CI Status Sub-Menu provides an extended menu of status monitoring
options on the Common Interface (CI) data.
Figure 3-16 shows the menu tree of status monitoring options available in the Decoder / CI
Status Sub-Menu. Table 3-12 describes the status parameters provided by the sub-menu
to the IRD operator.
Figure 3-16: Decoder / CI Status Sub-Menu Tree Structure
DECODER
STREAM CI VIDEO AUDIO
STATUS
CI (Slot 1)
Main Menu
CI (Slot 1)
Service Mode
CI (Slot 1)
CA Specifier
CI (Slot 2)
Main Menu
CI (Slot 2)
Service Mode
CI (Slot 2)
CA Specifier
