IRD-2600 / IRD-2800
Integrated Receiver Decoders
P/N 2349-72784-00 Page 3-45
3.3.3. Status / System Menu
The System Status Menu enables the IRD user review the current version of the IRD.
Figure 3-14 shows the menu tree flowchart to the Status/System Menu with an example of
message displayed on the LCD display. Table 3-15 describes the System Status Menu
options.
Figure 3-19: System Status Menu Tree
RECEIVER DECODER SYSTEM
Product
Version
CONFIG STATUS TEST RUN
Main Status
Display
Initialization
Password
Product Serial
Number
Table 3-15: System Status Menu Parameters
OPTION DESCRIPTION
Product Version
Product Version Information
Provides the current Version Code, Date, and Time.
Example format:
H/W BOOTMAINDATE
420 02:00 014 22 NOV 2000
Product Serial Number
Product Serial Number
Provides the product serial number in hex and decimal.
Example:
0003E8 hex 00001000 Dec
