IRD-2600 / IRD-2800
Integrated Receiver Decoders
P/N 2349-72784-00 Page 1-21
1.5.3. Control Ports Specifications
The IRD provides connections for terminal control on the IRD over RS-232 interface or
RS-485 Interface. Table 1-14 details the interface specifications.
Table 1-14: RS-232 Interface Specifications
PARAMETER SETTING
Protocol XON/XOFF
Baud Rate 9600, 19200, 38400, 57600, 115200
Data Bits 8
Parity N (None)
Stop Bits 2
Terminal Emulation ANSI/VT-100
1.5.4. Physical Features and Specifications
Table 1-15 summarizes the physical features and specifications of the IRD-2600 and
IRD-2800. Table 1-16 summarizes the electrical supply and consumption specifications of the
IRD-2600 and the IRD-2800, in both options, AC and DC supply.
Table 1-15: Physical Specifications
PARAMETER SPECIFICATION
Dimensions 1U
4.4 x 48.2 x 30.2cm (1.75" x 19" x 11.9")
Weight 2.5 Kg
Operating Temperature
-0°C ÷ +50°C
Operating Humidity
5% ÷ 85% (Non-condensing)
Storage and Transport
Temperature
-40° ÷ 70°C
NOTE
before operation after transportation of the equipment below
00C, wait for 12 Hours at room temperature.
Storage and Transport
Humidity
0% ÷ 95% (Non-condensing)
Table 1-16: Electrical Specifications
PARAMETER SPECIFICATION
AC Mains Supply
Power Source 100 - 240 V AC, 50/60 Hz
Power Consumption 50 W max. (all options)
-48V DC Supply
Supply voltage: 36VDC min. - 72VDC max.
Power consumption: 1 Amp. max
