IRD-2600 / IRD-2800
Integrated Receiver Decoders
P/N 2349-72784-00 Page 1-19
Table 1-11: SONET/SDH 155Mbit/s input
(In accordance with ETS 300 814)
Feature Specification
STM-1 155.52Mbit/s
(up to 60 Mbps for the selected TS)
Description: Single-mode/Multi-mode optical interface
Frame: STM-1/OC-3
Connectors: Duplex SC fiber optic
Wavelength: 1300 nm
Max selected TS bit rate Up to 60 Mbps
Loop-through output: Available
1.5.2. Output Specifications
Table 1-12 and Table 1-13 summarize the features and specifications of the IRD-2600 and
the IRD-2800 Video and Audio outputs, respectively.
Table 1-12: Video Decoder Output Features and Specifications
FEATURE SPECIFICATION
MPEG-2 standard Main Level at Professional Profile, and
Main Level at Main Profile
Standards decoded MPEG-1, MPEG-2
Decoded Output Resolution
• 720 by 480 at 30 Hz (NTSC)
• 720 by 576 at 25 Hz (PAL)
Encoded Input Resolution of
the IRD-2600
[Horizontal] by [Vertical] at [Frequency]
720, 704, 640,
544, 528, 480,
352, 320
480 30 Hz
720, 704, 640,
544, 528, 480,
352, 320
480 24 Hz
352 240 30 Hz
384, 352 240 24 Hz
720, 704, 640,
544, 528, 480, 352
576 25 Hz
720, 704, 640,
544, 528, 480, 352
288 25 Hz
