IRD-2600 / IRD-2800
Integrated Receiver Decoders
P/N 2349-72784-00 Page 1-3
1.1.1.2. Outputs
Video
• Analog video Interfaces: 2 composite, 1 S-Video
• Digital video Interfaces (optional):
2x SDI, with embedded VBI and up to 2 stereo
channels
• Video formats:
PAL-B/G/I/M/N/D, NTSC/SECAM L/B/G/K1
• Russian SECAM D/K (option applicable only in
composite video, available only for IRD-2600).
• Decoding:
4:2:0MP@ML (1.5 -15 Mbps)
4:2:2PP@ML (1.5 -50 Mbps) (IRD-2800)
• Video Resolution Interpolation:
Pan-Scan, Letter box or Pass-through
• Aspect ratio:4:3/16:9 and 14:9
• Graphic processing: OSD, DVB Subtitling,
EBU (Teletext) Subtitling.
• OSD only on monitoring output (optional)
• Sync Lock Input and Loopthrough output (optional)
VBI Re-Insertion
• In Composite video and embedded in SDI
• WST Teletext and inverted Teletext
• WSS, VPS, VITC, SMC, CC, AMOL (optional)
• Enhanced VITS with built-in generator
Audio
• Analog audio: up to 3 stereo pairs (up to 2 stereo
pairs in IRD-2600). All inputs balanced or 1st
unbalanced (optional)
• Digital audio (optional): up to 3 AES/EBU-SPDIF
(up to 2 on IRD-2600)
• Embedded in SDI (optional): up to 2 stereo
• Mode: Stereo, Joint Stereo, Dual Channel, Single
Channel
• Max output level: +24 dBu analog, 0 dBFs digital
• Gain Control: -58 to +6 dB /mute
• AC-3 Pass-through (optional)
• Linear PCM audio (IRD-2800)
Data
• Low Speed Data:
- RS-232 up to 115.2 Kbaud, or
- RS-422 (optional) up to 2Mbps
• High Speed Data: RS-422 up to 20 Mbps
Transport Stream Outputs
(options)
• 1st and 2nd ASI (optional): Copper, or Input stream
with selected program decrypted
• 3rd ASI (optional): Copper or Optical ,Input stream
or Loop-through
