User Manual
Chapter 1. Overview
Page 1-20 P/N 2349-72784-00
Table 1-12: Video Decoder Output Features and Specifications
FEATURE SPECIFICATION
Encoded Input Resolution of
the IRD-2800
[Horizontal] by [Vertical] at [Frequency]
720, 704, 544,
480, 352
480 30 Hz
352 240 30 Hz
720, 704, 544,
480, 352
576 25 Hz
352 288 25 Hz
4:2:2 Mode Only
720 512 30 Hz
720 608 25 Hz
Video Encoder 27 MHz with 10 bits resolution DAC (8 bits input)
Video formats decoded NTSC / PAL / SECAM standards and sub-standards
Video formats selection Automatic selection for NTSC / PAL
Standard Outputs 2 Composite Video outputs
S-Video (Y/C) output
Table 1-13: Audio Output Features and Specifications
FEATURE SPECIFICATION
Quality CD Quality 16 bit delta – sigma DAC
Sample rates 48 KHz, 44.1 KHz, 32 KHz, 24 KHz, 22.05 KHz, 16 KHz
Decoding Levels
• MPEG-2 Stereo
• MPEG-1 layer I and II
• AC-3 Dolby Digital Surround
®
pass-through
• Linear Audio on digital output (IRD-2800 Only)
Audio 1 Channel
• Balanced Stereo
• Unbalanced Mono/Stereo (option)
• AES/EBU (SP-DIF, option)
Audio 2 Channel (option)
• Balanced Stereo (option)
• AES/EBU (SP-DIF, option)
Audio 3 Channel (option)
ONLY for IRD-2800
• Balanced Stereo (option)
• AES/EBU (SP-DIF, option)
