IRD-2600 / IRD-2800
Integrated Receiver Decoders
P/N 2349-72784-00 Page 4-3
4.4. Common Status Messages
After the IRD initialization is completed, the IRD LCD displays the Common Status
Message. This message provides information on the IRD status and includes the following:
• General Status message (see paragraph 4.4.1).
• Hardware Failure messages (see paragraph 4.4.2).
• BIT Stream warning messages (see paragraph 4.4.3).
• Service Warning (see paragraph 4.4.4).
4.4.1. General Status Messages
The General Status messages are displayed on the IRD Main display, providing the IRD
status information. Figure 4-1 shows the structure of the message and table 5-1 lists and
describes the messages available
Figure 4-1: General Status Message Example
ALL OK! TV FRE
Service: MTV
Top Line
Bottom Line
The top line consists of three fields:
a. Left field – the message, as listed in Table 4-2.
b. Center(to the right) field - when “ALL OK!” message is displayed, this field displays the
service type provided (TV, Radio, DATA, etc.).
c. Right field - when “ALL OK!” message is displayed, this field displays the IRD operation
status:
• FRE: Free to Air, i.e., No CA descriptors
• CAS: Conditional Access System, i.e., CA descriptors detected.
• EN1: Enabled SLOT 1, i.e., descrambling of the selected service is possible by
module in slot 1.
• EN2: Enabled SLOT 2, i.e., descrambling of the selected service is possible by
module in slot 2.
The bottom line displays the service mode.
Table 4-2 General Messages
MESSAGE TYPE DESCRIPTION
ALL OK!
System System initialized and ready for use
Internal Test
System The system is performing an internal test on all
components and configurations.
