1.2.4. Configuration Options
Table 1-2 lists the configuration options available for the various IRD-2600/IRD-2800
Standard applications:
Table 1-2: IRD-2600 / IRD-2800 Configuration Options
OPTION NAME DESCRIPTION
OPT 002 ASI Out Two BNC type ASI Output (provides full transport stream, with
the selected service decrypted).
When used with front-end input: Active Interface Conversion to
ASI.
OPT 003 Russian Secam Russian Secam, on the broadcast output only. (Built-in with
OPT 006) Available only for IRD-2600.
OPT 004 Unbalanced 1st Stereo Unbalanced Audio RCA on First Stereo Channel, instead of the
XLR balanced output
OPT 005 AES/EBU, or
AC-3 Pass through
OPT 005.1: AES/EBU (SP-DIF) for 1st stereo
OPT 005.2: AC-3 Pass-through or AES/EBU, menu selectable
NOTE
Default connector: Unbalanced BNC.
Option connector: Balanced XLR connector.
OPT 006 Monitoring Video Output One broadcast and one monitoring output (OPT 006)
Two identical video outputs (Default Configuration)
OPT 007 IR Infra-red Remote Control
OPT 008 -48V DC -48V DC power interface (Replacing the 110-230V AC)
OPT 101 SDI 2 x SDI with embedded audio and VBI
(Embedded dual stereo when ordered with option 102)
OPT 102.1 2nd Stereo Analog 2nd Stereo: Analog Balanced over XLR
OPT 102.2 2nd Stereo Digital 2nd Stereo: AES/EBU(SP-DIF) over BNC
OPT 102.3 2nd Stereo Analog &
Digital
2nd Stereo: Analog Balanced over XLR and AES/EBU
(SP-DIF) over BNC
OPT 103.1 3rd Stereo Analog 3rd Stereo: Analog Balanced over XLR
(IRD-2800 ONLY)
OPT 103.2 3rd Stereo Digital 3rd Stereo: AES/EBU(SP-DIF) over BNC
(IRD-2800 ONLY)
OPT 103.3 3rd Stereo Analog &
Digital
3rd Stereo: Analog Balanced over XLR and AES/EBU
(SP-DIF) over BNC (IRD-2800 ONLY)
OPT 104 ASI In + Loop-through,
BNC
ASI TS In + out (without decryption), Auto 188/204, BNC. ASI
out provides Auto Active/Passive Loop-through. When used
with front-end input: Active Interface Conversion to ASI.
OPT 105 ASI In + Loop-through,
Optical
ASI TS In + out (without decryption), Auto 188/204, Optical.
Active Loop-through. ASI out provides front-end input
Conversion to ASI.
NOTE
Conflicts with Sync Lock
OPT 106 Sync Lock Sync Lock and Loop-through
