User Manual
Chapter 3. Operation
Page 3-64 P/N 2349-72784-00
Figure 3-31: Product Status / Product Revision Overlay - Example
Figure 3-32: Product Status / Product Setups Overlay - Example
PRODUCT COMPONENT (hard & soft) Versions :
CPU - SOFTWARE : MC68302-20 - Rev 02-00.50 Oct 14 2001 08:37:48.
DECODER CARD LAYOUT : SP340 B - .
MPEG2-DVB DEMUX : DMX-GTX C0 - Microcode 1.30.
A/V DECODER : AVIA-60xL E0 - Microcode 0.22.
VIDEO ENCODER : SAA7129 H - .
AUDIO DAC : CS4341 A - .
XILINX1 : XCS40xl A - .
BACK PANEL (OPTION) : OPTIMA A - 0334.
AUDIO2 DECODER : CS4922 A - Microcode 4.01.
XILINX2 : XCS40xl A - .
PRODUCT SERVICE SETUPS :
Num | Frequency (GHz) | Symbol R (Msm) | Viterbi | LNB | Service
ID
*** | **************** | ************** | ******* | *********** |
**********
000 | 01.488000 | 27.50000 | AUTO | 18V + 22KHz | 0x0006
001 | 01.488000 | 27.50000 | AUTO | 18V + 22KHz | 0x0001
002 | 01.488000 | 27.50000 | AUTO | 18V + 22KHz | 0x0002
003 | 01.488000 | 27.50000 | AUTO | 18V + 22KHz | 0x0003
004 | 01.488000 | 27.50000 | AUTO | 18V + 22KHz | 0x0004
005 | 01.488000 | 27.50000 | AUTO | 18V + 22KHz | 0x0005
006 | 01.488000 | 27.50000 | AUTO | 18V + 22KHz | 0x0006
007 | 01.488000 | 27.50000 | AUTO | 18V + 22KHz | 0x0007
008 | 01.488000 | 27.50000 | AUTO | 18V + 22KHz | 0x0008
009 | 01.488000 | 27.50000 | AUTO | 18V + 22KHz | 0x0009
