User Manual
Chapter 2. Installation
Page 2-12 P/N 2349-72784-00
Table 2-8: QPSK Receiver Configuration Procedure
SEQ.
#
MENU DISPLAY MESSAGE PROCEDURE
a.
RECEIVER CONFIGURATION
Function Start.
The CONFIG sub menu is displayed.
Select the RECEIVER option and proceed to configure as
described below.
b.
Frequency Range Parameter 1. Select Frequency Range option.
2. Set the frequency according to the BAND input.
c.
LNB Power Supply Parameter 3. Select LNB Power Supply option.
4. Set the LNB Power Supply to: 14, 18 or OFF as
required
d.
LNB 22 kHz Parameter 5. Select LNB 22 kHz option.
6. Using the controls, set the option to ON or OFF as
required
e.
Symbol Rate Parameter 7. Select Symbol Rate option.
8. Set the Symbol Rate as required.
f.
Viterbi Rate Parameter 9. Select Viterbi Rate option.
10. Set to: 1/2, 2/3, 3/4, 4/5, 5/6, 6/7, 7/8, 8/9, or
AUTOMATIC as required.
g.
Spectral Inversion Parameter 11. Select Spectral Inversion option.
12. Set the option to AUTOMATIC, NORMAL, or
INVERTED as required.
Table 2-9: QAM Receiver Configuration Procedure
SEQ.
#
MENU DISPLAY MESSAGE PROCEDURE
a.
RECEIVER CONFIGURATION
Function Start.
The CONFIG sub menu is displayed.
Select the RECEIVER option and proceed to configure as
described below.
b.
VHF/UHF Frequency
Configuration Option
1. Select VHF/UHF Frequency option.
2. Set the required input frequency.
c.
Symbol Rate Parameter 3. Select Symbol Rate option.
4. Set the symbol rate as required.
d.
Viterbi Rate Parameter 5. Select Viterbi Rate.option.
e.
Modulation Mode Parameter
6. Set the QAM mode to:
16 QAM, 32 QAM, 64 QAM, 128 QAM, or 256 QAM,
as required.
f.
Spectral Inversion Parameter 7. Select Spectral Inversion option.
8. Set the option to AUTOMATIC, NORMAL, or
INVERTED as required.
