User Manual
Chapter 3. Operation
Page 3-42 P/N 2349-72784-00
Table 3-13: Decoder / Video Status Sub-Menu Parameters
OPTIONS DESCRIPTION
Video Format
Current Video Format
Displays the video format currently used (as configured in the Decoder/
Video Configuration Sub-Menu, refer to paragraph 3.2.2.3).
Options available: PAL B/G, PAL M, NTSC, PAL D, SECAM, PAL N.
Video Chroma
Current Video Chroma Format
Displays the Chroma format currently used for the incoming video stream:
Options available: 4:2:0 (4:2:0 and 4:2:2 are available only in IRD-2800)
Video Aspect Ratio
Current Video Aspect Ratio
Displays the aspect ratio for the incoming video stream.
Options available: 4:3, 16:9
Video Resolution
Current Video Resolution
Displays the horizontal and vertical video resolutions for the incoming
video stream (i.e., the number of pixels per horizontal and vertical screen
lines).
Video Bit Rate
Current Video Bit Rate
Displays the bit rate, in bits/sec, for the incoming video stream.
Teletext Line Count
Current Teletex Line Count
Shows the number of Teletext lines detected on each video field.
