Instructions for Use
Resting & Stress ECG with seca
ct330/331 and seca diagnostic 5.9
3.2.5 Extended ECG settings
Changing the ECG colour scheme:
The ECG colours are preset in seca diagnostic and can be changed
under Examination, Settings, System, ECG colour. Click on Save to
apply your changes.
ECG Grid:
The ECG grid in seca diagnostic corresponds to normal ECG paper. The
small boxes measure 1 * 1 mm, the large boxes 5 * 5 mm. To ensure the
graph paper is correctly displayed on the screen, the screen diagonal of
the monitor must be specified in the seca service center. Contact your
authorized seca dealer.
Resting ECG, automatic ECG procedures:
Under Examination, Resting ECG, Settings, Menu/Functions, Workflow
procedures for automatic ECG recordings can be set in the “Automatic
ECG” area. For example, recording duration and procedures after
recording. Click on Save to apply your changes.
Procedures for manual resting ECG recordings and stress ECG:
Under Examination, Resting ECG or Stress ECG, Settings,
Menu/Functions, Workflow procedures after recording and the display
options in the evaluation can be set in the “Workflow” area. Click on
Save to apply your changes
Print settings for resting ECG:
On the Examination, Resting ECG, Settings, Print, Printed pages
screen, you can set the contents for various printouts. Select the desired
entry in the “Type of printout” list, for example automatic printout
(Automatic ECG). In the “Printout” area, select the contents for the
printout after an automatic ECG. Click Save to apply your changes.
Print settings for stress ECG:
On the Examination, Stress ECG, Settings, Print, Printed pages screen,
you can specify the contents for different printouts. Select the desired
entry in the “Type of printout” list and compose the contents of the
printout. Important: This setting is only required if the automatic ECG
print pages contains content other than the standard printout (see “Type
of printout” Standard). Click on Save to apply your changes.
