Secure Care 135DE - 135 DE Exit Panel to External Receiver Connections; Figure 9-12 Exit Panel to External Receiver Connection

A01350693 Rev:P ECO: 7476 Date: 04/14/08 33
135DE Exit Panel to External Receiver Connections
Enabling the External Antenna or range adjustment is done through the keypad on the Exit Panel.
Figure 9-12 Exit Panel to External Receiver Connection
SECTION 9 INSTALLATION AND CONNECTIONS
+ - Out In
FIRE PUSH DOOR EGRESS
LOCK AUX
CAN
L
CANHGND
SECURE CARE PRODUCTS
AUXLOCK
- +
NO C NC NO C NC NO C NC NO C NC
- +
KEYPAD
O N
1 2 3 4
1 2 3 4 5 6 7
1 2 3 4
3 to -
2 to +
1 to Out
