A01350693 Rev:P ECO: 7476 Date: 04/14/08 41
Antenna Selection
Each 135DE Exit Panel has an integrated antenna system in the unit. However, due to special requirements of certain
installations, you may be inclined to add an external antenna to the 135DE Exit Panel. In order to choose the external
antenna solely for coverage or choose both antennas, the following steps will allow you to choose the proper setup for your
installation needs.
Antenna Selection
1. To change the selection of antennae:
2. Enter *567 (or Currently Programmed Secondary Code) Enter *5 and hold the 5
3. One beep = board antenna is active
4. Two beeps = remote antenna is active
5. Three beeps = both the on board antenna and remote antennas are active
6. Four beeps = neither antennas are active
Antenna Range Adjustment
Each door system installation will be unique in many ways. Consider all of the local environmental factors of construction around
the system location - the types of materials used, the construction methods used, and amount of foot traffic around and through the
door
area. Each system will require tuning for the required coverage at each location independently. The following steps will guide you
during the adjustment.
Antenna Range Adjustment
1. Enter *567 or currently programmed secondary code *9876543219
Five beeps indicate that you are in range adjustment mode
2. Enter “1” and the current threshold will be given via a series of beeps.
1-9 beeps indicate its numeric value.
Ten beeps indicate a value of zero.
3. Enter “*” followed by three digits
of desired threshold value
Higher the value = shorter range
Lower the value = longer range
4. Enter “0” to select the on board antenna or remote antenna
Four beeps = adjust the remote antenna
Two beeps = adjust the onboard antenna
5. Enter “#” to get out of the range change mode or wait one minute.
Three beeps = end of range adjustment mode.
SECTION 10 PROGRAMMINGSECTION 10 PROGRAMMING
