9. ▷
Only in case of an Inverse-Time characteristic:
Specify the »IG>« Earth (Ground) Overcurrent tripping characteristic factor (see ╚═▷
“Explanation for All Characteristics (IG>, IG>>)” for details):
• [Protection Para / IG>] »IG> . tChar«•
10. ▷
If Inrush Blocking has been activated (see ╚═▷ “4.4 IH2 - Inrush Blocking”), select
whether this Earth (Ground) Overcurrent stage shall be blocked in case of an inrush
current:
• [Protection Para / IG>] »IH2 Blo« =•
Options:
◦ “Inactive” (no Inrush blocking of the ground overcurrent protection),◦
◦ “Active” (the Inrush Blocking module also blocks the ground overcurrent◦
protection).
152 WIC1 WIC1-1.0-EN-MAN
4 Protective Elements
4.5.2.1 Earth (Ground) Overcurrent Protection – Settings via DiggiMEC or via Smart view
