11.1.3.4 DIP-/HEX-Switch Settings for CT Type W5
CT Type W5
Primary Rated CT
Current In in
Ampere
Relative Rated
Current
»In,relative«
in In
,min
(Prim. Rated
Current for WIC1-
W5 = 128 ⋅ Relative
Rated Current)
HEX 1 DIP 1-1 DIP 1-2 DIP 1-3 DIP 1-4
128 1.0 0 OFF OFF OFF OFF
144 1.125 1 ON OFF OFF OFF
160 1.25 2 OFF ON OFF OFF
176 1.375 3 ON ON OFF OFF
192 1.5 4 OFF OFF ON OFF
208 1.625 5 ON OFF ON OFF
224 1.75 6 OFF ON ON OFF
240 1.875 7 ON ON ON OFF
256 2.0 8 OFF OFF OFF ON
272 2.125 9 ON OFF OFF ON
288 2.25 A OFF ON OFF ON
320 2.5 B ON ON OFF ON
352 2.75 C OFF OFF ON ON
384 3.0 D ON OFF ON ON
416 3.25 E OFF ON ON ON
448 3.5 F ON ON ON ON
258 WIC1 WIC1-1.0-EN-MAN
11 Appendix
11.1.3.4 DIP-/HEX-Switch Settings for CT Type W5
