6.1 Device Start (Reboot)
The WIC1 starts (or reboots) in any of the following situations:
• It is connected to the supply voltage (or gets sucient electrical energy from the•
CTs),
• the user initiates (intentionally) a restart of the device,•
• the device is set back to factory defaults,•
• the internal self-supervision of the device detects a fatal error.•
Note that every WIC1 restart also triggers a DiggiMEC restart, if connected. If a PC with
Smart view is connected, then the connection is lost. To reconnect, close the previous
session in Smart view (menu item [File / Close]), then select [Device / Receive Data
from Device].
Every restart of the WIC1 – except for a normal start-up – appears as a new entry within the
Self-Supervision messages, ╚═▷ “6.2 Self-Supervision Messages”.
The reason for a device start/reboot is shown numerically as “Value”. The value “1” in the
example above means a normal start-up. Please see the table below for a full list.
Device Start-up Codes
1. Normal Start-up
Start-up as a normal cold restart.
2. Reboot by the Operator
Device reboot triggered by the operator via HMI or Smart view.
3. Forced Reboot (initiated by the WIC1 processor)
The WIC1 processor identied invalid conditions or data.
4. Illegal Memory Access
Reboot after illegal memory access.
5. Exceeded Time Limit of the Protection Cycle
Unexpected interruption of the Protection Cycle.
6. Sags of Power Supply
Reboot after short-term sag or outage of the supply voltage / current via CTs.
12. Reset to Factory Defaults
Restart that is carried out due to reset to factory defaults.
(See also ╚═▷ “2.12 Reset to Factory Defaults”.)
13. Return from Backup Protection into normal operation
After a transition into the operating mode “Backup Protection”, the WIC1 returns to normal operation after
approx. 10 seconds via an automatic restart. (See also ╚═▷ “4.13.1 Activation of the Backup Protection”.)
184 WIC1 WIC1-1.0-EN-MAN
6 Self-Supervision
6.1 Device Start (Reboot)
