5.2 Content of a Fault Record
A fault record comprises information about:
Part 1: Common Information (independent of protection function)
Runtime (Startup No.) Timestamp of the Fault. This speci󰊟es the uptime of the WIC1, and the
total number of WIC1 restarts (in parentheses).
Example: 1d 01:14:23.848 (4) — The fault occurred at 1 day, 1 hour,
14 minutes, 23.848 seconds after the 4
th
restart. (Restarts counted from
WIC1 delivery.)
Fault No. This counter will be incremented with each fault (i. e. with every
(General) Pickup »Prot . Pickup«).
Time to trip The time between pickup and trip. Please note: No time to trip will
be shown if the 󰊟rst pickup and the 󰊟rst trip are issued by di󰊞erent
protection stages or modules.
Pickup Name of the module / protection stage that picked up 󰊟rst.
Trip Name of the module / protection stage that tripped 󰊟rst.
Part 2: Information depending on the active settings
Measured Values Various measuring values at the time of the pickup or trip are displayed.
181WIC1WIC1-1.0-EN-MAN
5 Fault Recorder
5.2 Content of a Fault Record
