IG> Setting of the IG> threshold
DIP 4-1 OFF ON OFF ON OFF ON OFF ON OFF ON OFF ON OFF ON OFF ON
DIP 4-2 OFF OFF ON ON OFF OFF ON ON OFF OFF ON ON OFF OFF ON ON
DIP 4-3 OFF OFF OFF OFF ON ON ON ON OFF OFF OFF OFF ON ON ON ON
DIP 4-4 OFF OFF OFF OFF OFF OFF OFF OFF ON ON ON ON ON ON ON ON
HEX switch 7 0 1 2 3 4 5 6 7 8 9 A B C D E F *
Resulting setting IG>
[In] →
0.2 0.3 0.4 0.5 0.6 0.7 0.8 0.9 1 1.2 1.4 1.6 1.8 2.0 2.5 — *
Hex 1 = „D“ (In = 3.0) 0.192 0.288 0.384 0.480 0.576 0.672 0.768 0.864 0.960 1.152 1.344 1.536 1.728 1.920 2.400 — *
Hex 1 = „E“ (In = 3.25) 0.208 0.312 0.416 0.520 0.624 0.728 0.832 0.936 1.040 1.248 1.456 1.664 1.872 2.080 2.600 — *
Hex 1 = „F“ (In = 3.5) 0.224 0.336 0.448 0.560 0.672 0.784 0.896 1.008 1.120 1.344 1.568 1.792 2.016 2.240 2.800 — *
— * This DIP / HEX setting deactivates the protection stage.
199WIC1WIC1-1.0-EN-MAN
7 Commissioning
7.1.6.1 Tripping Thresholds for the Calculated Ground Overcurrent Stage IG>
