Setting of the Pickup Current of Phase Overcurrent Protection Stage I>
WIC1‑2: DIP switch block 2, switches 1…4
WIC1‑3: HEX switch 3
If “DEFT” is set as the characteristic (╚═▷ “Setting of the Characteristic of Phase Overcurrent
Protection Stage I>”) this is the setting I> for the pickup current.
If any of the inverse characteristics is set (╚═▷ “Setting of the Characteristic of Phase
Overcurrent Protection Stage I>”) this is the start value of the inverse-time characteristic.
The pickup currents in this table are given in units of the rated CT current In. (╚═▷ “11.1.3
Setting of the Rated CT current In”)
Pickup
»I> . I«
(as a multiple of In)
HEX 3 DIP 2-1 DIP 2-2 DIP 2-3 DIP 2-4
0.90 0 OFF OFF OFF OFF
0.95 1 ON OFF OFF OFF
1.00 2 OFF ON OFF OFF
1.05 3 ON ON OFF OFF
1.10 4 OFF OFF ON OFF
1.15 5 ON OFF ON OFF
1.20 6 OFF ON ON OFF
1.30 7 ON ON ON OFF
1.40 8 OFF OFF OFF ON
1.50 9 ON OFF OFF ON
1.60 A OFF ON OFF ON
1.80 B ON ON OFF ON
2.00 C OFF OFF ON ON
2.25 D ON OFF ON ON
2.50 E OFF ON ON ON
This setting deactivates the
protection stage.
F ON ON ON ON
261WIC1WIC1-1.0-EN-MAN
11 Appendix
11.1.4 Phase Overcurrent Protection – Settings via DIP Switches (WIC1‑2) or via HEX Switches (WIC1‑3)
