3.7. Assembly Instructions
•
Perform the assembly by following the procedure herein stated. Failure to
comply with the instructions, for example, inserting the plug into an outlet at a
stage not mentioned in this manual can cause an electric shock
•
Assembling should be performed as per this manual. Since this is a complex
machine, erroneous assembling can cause damage to the machine, or
malfunction to occur.
• Do not attempt to complete this work alone, a minimum of 2 people are required.
• Only QUALIFIED SERVICE PERSONNEL should carry out assembly.
When carrying out the assembly work, follow the procedure in the following sequence:
STEP 1 INSTALLING THE BILLBOARD
STEP 2 INSTALLING THE FLOOR
STEP 3 CONNECTION TO THE POWER SUPPLY
STEP 4 ASSEMBLY CHECK
Note that the parts contained within the installation kit are required for the assembly work.
The following tools will be required when installing this machine:
