Sega Outrun 2 - Ptr-1110 Uk Assy Framework Black New

93
8.4. PTR-1110UK ASSY FRAMEWORK BLACK NEW
Item Component Part Description QTY Component Reference
1
PTR-1602UK BASE BOX SFMD BLACK 1
2
PTR-1101UK MAIN FRAME U/R R (BLACK) 1
3
PTR-1102UK MAIN FRAME U/R L 1
4
NOA-1111X LOWER BEAM 1
5
NOA-1112X UPPER BEAM 1
6
NOA-1113 HOOF R 1
7
NOA-1114 HOOF L 1
8
PTR-1950UK ASSY SFMD BLACK (FLAT DOOR) 1
9
253-5366 CASH BOX 1
11
NOA-1115UK TNG REAR HATCH 1
102
601-5699X LEG ADJUSTER BOLT M16x75 SEGA 2
103
601-10461UK CASTOR 50 SWIVEL 2
104
601-10462UK CASTOR 50 FIXED 2
105
220-5575UK LOCK 1
201
050-F00600 M6 NUT FLG SER PAS 4 (2)-2,(3)-2
202
030-000620-S M6X20 BLT W/S PAS 14 (2)-3,(3)-3,(4)-4,(5)-4
203
068-652016 M6 WSHR 20OD FLT PAS 6 (2)-3,(3)-3
204
050-F00500 M5 NUT FLG SER PAS 2 (6)-1,(7)-1
205
000-P00408-W M4X8 MSCR PAN W/FS PAS 2 (6)-1,(7)-1
207
050-H01600 M16 NUT PAS 2 (102)-2
208
FAS-200004 M6X14 SKT CAP BLK 16 (103)-8,(104)-8
209
060-S00600-0B M6 WSHR SPR BLK 16 (103)-8,(104)-8
