3.7.4. Connection To The Power Supply
•
Be sure that the machine is not connected to the mains supply before attempting
this operation
• Only QUALIFIED SERVICE PERSONNEL should carry out this operation.
1. The AC Unit is located on the right hand side of the base unit, when viewing the screen. It houses the
IEC inlet, mains switch and fuse.
2. Ensure that all of the machine’s wires have been connected in accordance with the preceding Sections
and that the mains switch is OFF.
3. Check that the operating voltage of the mains supply matches the machine (Section 1.1).
4. Insert the IEC lead into the IEC inlet and the mains plug into a wall socket. If applicable, switch the wall
socket ON.
5. Stand clear of the machine and switch the mains switch ON.
