3.12. Replacement Of Fluorescent Lamps
•
Never touch places other than those specified. Touching places other than those
specified can cause electric shock and short circuit. Disconnect the machine
from the supply before attempting the replacement of any lamp.
• When performing work, be sure to turn power off. Working with power on can
cause an electric shock or short circuit.
• Hot fluorescent lamps can cause burns. Be very careful when replacing them.
• Use a secure step to improve access to the upper parts of the cabinet.
• Only QUALIFIED SERVICE PERSONNEL should replace lamps.
3.12.1. Front Fluorescent:
1. Turn power OFF at the Main Switch and remove the IEC lead.
2. Open the Control Panel (see Section 3.9).
3. Remove the two truss screws and open the entry panel.
