Slightly lower the 2 Adjusters on the cabinet and install JOINT BRACKET L & R by inserting from
the rear, and secure to ASSY FLOOR using hexagon bolts as shown.
•
Make sure all of the leg adjusters are in contact with the floor. If they are not the
machine may move and cause injury. This operation requires 2 people.
•
Only QUALIFIED SERVICE PERSONNEL should carry out this operation.
ˆ
After lowering the Adjusters fully downward so that they raise both front castors 7mm from the
floor, tighten both Adjuster’s lock nuts fully upward.
‰ If this product is installed on irregular surfaces, use the two Level Adjusters on the bottom of the
FLOOR to ensure the product is level.
