10R
12
3. Align the arrows on the main unit and speaker cables and insert
speaker cables into each speaker connector.
Note:
1. Three cables connect to the main unit. The longest is the cable for the
speakers. The second longest cable has a male connector and is for the
battery pack. The shortest cable is for the microphone.
2. The cable for the speakers has two leads. The longer lead is for the right
speaker and the shorter lead is for the left speaker.
3. If the helmet has deep ear pockets, you can use the speaker pads to
bring the speakers closer to your ears.
3.3 Installing the Microphones
3.3.1 Using the Wired Boom Microphone
1. Peel off the cover of the hook and loop fastener for wired boom
microphone to expose the adhesive tape. Then, attach the hook
and loop fastener on the inside surface of the left external shell.
To Next Page
