Sena 10R - Page 13

10R
13
English
2. Attach the wired boom microphone’s mounting plate to the hook
and loop fastener.
Note:
1. After you install the wired boom microphone, make sure you reinstall the
helmet’s internal padding.
2. You can use the boom microphone holder after attaching the hook and
loop fastener for boom microphone holder on it to ensure secure
installation.
3. Make sure that the microphone’s receiver is located near your
mouth.
4. Adjust the head of the microphone so that the tab is facing away
from your mouth.
Tab
5. Align the arrows on the main unit and microphone cables and
insert the microphone cable into the microphone connector.
Note:
Three cables connect to the main unit. The longest is the cable for the
speakers. The second longest cable has a male connector and is for the
battery pack. The shortest cable is for the microphone.
