3.3.2 Using the Wired Microphone
If you have a full face helmet, you can use the wired microphone.
1. Peel off the cover of the hook and loop fastener for wired
microphone to expose the adhesive tape. Then, attach the hook
and loop fastener on the inside of the helmet’s chin guard.
2. Attach the wired microphone to the hook and loop fastener for
wired microphone.
3. Align the arrows on the main unit and microphone cables and
insert the microphone cable into the microphone connector.
Note:
Three cables connect to the main unit. The longest is the cable for the
speakers. The second longest cable has a male connector and is for the
battery pack. The shortest cable is for the microphone.
