OmniHub 6/6D– User Manual
Page 10 of 182
1.1 Product Overview
OmniHub 6/6D is a compact, highly integrated and flexible solutions that focuses on both
cost-effective commercial TV market and traditional DTV market. Thanks to the benefits
of high-density, strong-performance and large-flexibility, OmniHub 6/6D can meet all the
major video delivery requirements of receiving, descrambling, encoding, multiplexing,
modulation, and IP processing of signal in one unit.
With optional commercial/broadcast encoder, multi-mode receiver and modulator module,
it can be configured flexibly to meet any video delivery requirements. Due to its compact
design and powerful function, it can be widely used at hotel, hospital, communities, clubs,
campuses and or other places with DTV headend, where massive programs are required
to be processed in a cost-effective way. OmniHub 6/6D provides a straight-forward web
interface accessible via all major browsers and complete control of the unit. Every
OmniHub 6/6D is shipped with the software suite pre-loaded on appropriate hardware.
There are optional input and output configurations that will change the physical
connectors available on the chassis.
1.2 Front Panel Overview
As a 1RU unit, on the front panel, OmniHub 6 has exhaust fans, ports for data and
management, and LED for the status of the unit. See the image below for the reference
of the OmniHub 6 front panel.
1. Vent holes for cooling intake
2. Four 1GbE RJ45 ports: two for management and two for MPEG over IP purposes
3. Status indicators of the chassis and modules
Power indicators of the chassis and modules
