OmniHub 6/6D– User Manual
Page 86 of 182
3.5.2 OHM6-QAMA-R01/R01A
OHM6-QAMA-R01 and OHM6-QAMA-R01A are 4 channel and 8 channel modulators.
They share the same hardware but have different software. For the Status, Settings,
Service Configuration and System Operation, please refer to previous module OHM6-
QAMA-00/R00 at page 74 to 77.
3.5.3 OHM6-QAMB-00/R00
OHM6-QAMB-00 / R00 module supports up to 16 non-adjacent frequencies modulating
with 1 RF female connector for output.
3.5.3.1 Module Status
Please see OHR6-DVBC-00 on page 30 for reference. See also the image for QAMB
Status.
