OmniHub 6/6D– User Manual
Page 90 of 182
Name
Range
Name
Range
Bandwidth
6M, 7M, 8M
RF level
0~31.5 (dBmV)
60~91.5 (dBuV)
Frequency (KHz)
48000~862000
3.5.6.2 Module Output
Configuration of the OFDM module is like the configuration of OHM6-QAMA-00/R00.
You can also change the Original Network ID, TSID, Service Name, PID and create LCN
Descriptor and Cable Descriptor. For more details, please check OHM6-QAMA-00 on
page 74 for reference.
3.5.7 OHM6-ISDBT-R01/R01A
OHM6-ISDBT-R01/R01A module supports up to 4/8 adjacent frequencies modulating
with 1 RF female connector for output.
3.5.8 OHM-QAMA-02/02A、OHM-QAMB-02/02A
OHM-QAMA-02 is a 16-channel QAM-A modulation module, 2 gigabit IP input electrical
ports, each input port supports 512 channels; 1 CAS interface (RJ45), support
scrambling function; 1 RF output interface, support 16-channel QAM-A non-advanced
frequency Modulation output, independent constellation mode configuration.
OHM-QAMA-02A is a 32-channel QAM-A modulation module, support 32-channel QAM-
A non-advanced frequency Modulation output, other function descriptions are the same
as OHM-QAMA-02.
