OmniHub 6/6D– User Manual
Page 11 of 182
4. Reset Button
1.3 Rear Panel Overview
The OmniHub 6 has multiple options for the backplane configuration. Device can be
ordered with Single Power Supply (order number – OmniHub 6) or Dual Power Supply
(order number – OmniHub 6D).
Rear panel of the device with single power supply:
1. Slot no.1 for the option module
2. Slot no.2 for the option module
3. Slot no.3 for the option module
4. Slot no.4 for the option module
5. Slot no.5 for the option module
6. Slot no.6 for the option module
7. Ground
8. Single Power Supply
Rear panel of the device with dual power supply:
1. Slot no.1 for the option module
2. Slot no.2 for the option module
3. Slot no.3 for the option module
4. Slot no.4 for the option module
5. Slot no.5 for the option module
6. Slot no.6 for the option module
7. Ground
8. Dual Power Supply
1.4 Option Module Overview
This describes the OmniHub 6/6D platform and all available modules that can expand
the functionality of the OmniHub 6/6 platform.
1RU chassis, Single PSU, 4xGbE ports,
14 LEDs and six hot swappable slots
