OmniHub 6/6D– User Manual
Page 14 of 182
OHM6-QAMA-R00
16 channel QAM modulator module,
Annex A/C, non-adjacent output, and 1
RF female port for output
OHM6-QAMB-R00
16 channel QAM modulator module,
Annex B, non-adjacent output, and 1 RF
female port for output
OHM6-QAMA-R01
4 channel QAM modulator module,
Annex A/C, adjacent output, and 1 RF
female port for output
OHM6-QAMA-R01A
8 channel QAM modulation module,
Annex A/C, adjacent output, and 1 RF
female port for output
OHM6-QAMB-R01
4 channel QAM modulation module,
Annex B, adjacent output, and 1 RF
female port for output
OHM6-QAMB-R01A
8 channel QAM modulation module,
Annex B, adjacent output, and 1 RF
female port for output
OHM6-OFDM-R01
4 channel OFDM modulation module,
adjacent output, and 1 RF female port
for output
OHM6-OFDM-R01A
8 channel OFDM modulation module,
adjacent output, and 1 RF female port
for output.
OHM6-ISDBT-R01
4 channel ISDBT modulation module,
adjacent output, and 1 RF female port
for output.
OHM6-ISDBT-R01A
8 channel ISDBT modulation module,
adjacent output, and 1 RF female port
for output
OHM6-8VSB-R01
4 channel 8VSB (ATSC) modulation
module, adjacent output, and 1 RF
female port for output
OHM6-8VSB-R01A
8 channel 8VSB 9ATSC) modulation
module, adjacent output, and 1 RF
female port for output.
Function Modules
Description
