OmniHub 6/6D– User Manual
Page 175 of 182
HDMI Encoder (Professional)
Input 4 channels via 4 HDMI female
connectors (HDMI 1.4)
Video H.264 / AVC HD: MP/HP@L4.0
SD: MP/HP@L3.0
MPEG-2 SD: MP@ML
Resolution SD: 576i50,
480i59.94
HD: 1080p@25/30/50/59.94/60,
1080i@50/59.94/60,
720p@50/60
Bitrate Control CBR / VBR
Video Bitrate 1,000 ~ 14,000Kbps
GOP Structure IBBP, IPPP, IBP
GOP Size 6~63
Aspect Ratio Automatic or Manual
Audio MPEG-1 Layer II, AAC (Optional), AC3
(Optional)
Audio Bitrate 32~384Kbps
Audio Mode Stereo (2.0, including downmix)
Audio Sampling Rate 48KHz
Audio Volume Leveling -20dB~20dB
HDMI Encoder 02
Input 2 channels via 2 HDMI or 2 component
female connectors (HDMI 1.4)
CC/Component input via DB15 port
Video H.264/AVC HD: MP/HP@L4.0,
SD: MP/HP@L3.0 MPEG-2
SD: MP@ML HD: MP@HL
Resolution SD: 576i50,
480i59.94f
HD: 1080p25/30/50/59.94/60,
1080i50/60,
720p50/60
*The maximum output resolution is
1080i60
Bitrate Control CBR
Video Bitrate 1000 ~ 18,000Kbps
