The SL Handheld DW
119
Meaning of the status LED on the handheld trans-
mitter
lights up green:
• A radio link to the receiver is established. The accupack of
the handheld transmitter is sufficiently charged.
flashes green:
• The PAIR button has been short-pressed. Paired devices are
being identified.
flashes alternately green and red:
• The PAIR button has been long-pressed. The handheld
transmitter establishes a radio link to a receiver whose PAIR
button has also been long-pressed.
lights up yellow:
• The handheld transmitter has been muted with theMUTE
switch. In addition, Muted is displayed on the display panel.
flashes yellow:
• The firmware is being updated.
lights up red:
• No radio link to a receiver. In addition, No Link is displayed
on the display panel.
flashes red:
• The accupack capacity of the handheld transmitter is only
sufficient for max. 30 minutes of operation.
