The CHG 4N charger

192

• Name and installation location are reset, provided they

were changed in the Sennheiser Control Cockpit.

►

Updating the firmware

The firmware of the CHG 4N charger is updated using the

Sennheiser Control Cockpit software. You can find more in-

formation about this procedure in the software instruction

manual in the Sennheiser Documentation app or in the down-

load area of the Sennheiser website at www.sennheiser.com/

download.

Sennheiser Control Cockpit instruction manual

Download area for the Sennheiser website
