Recommendations on antenna mounting
48
Option 4: Rack mounting - rear
If you cannot mount the antennas at the front of the rack (op-
tion 3), you can also mount them at the rear of the receiver in
the rack. When mounting, observe the following information.
▷ Position the antennas so that they point at a 180-degree an-
gle away from the receiver.
▷ Run all cables close to the receivers to prevent the cables
from interfering with the antenna reception. Use the cable
grip.
▷ For best system performance, make sure that the antennas
are not covered or shielded by blocking obstacles such as
cables, metal plates, or cases.
▷ In this case, and if possible, make sure that there is a direct
line of sight between the transmitters and the receivers for
best possible RF performance.
►
