The AWM 2 antenna wall mount

198

Product overview

►

1 Rod antennas

• for connection to the R-SMA sockets at the top of the an-

tenna wall mount

2 R-SMA sockets of the antenna cables

• Antenna inputs for connecting the rod antennae

3 Antenna holes

• for screwing the R-SMA sockets of the antenna cables in

place
