Recommendations on antenna mounting

Antenna mounting options

There are different options for remote mounting the antennas.

We recommend the following four options in the specified or-

der.

>> „Option 1: Connecting the AWM 2 or AWM 4 antenna wall

mount directly to the receiver(s)“

>> „Option 2: Combining multiple links to one AWM 2/AWM 4“

>> „Option 3: Rack mounting - front“

>> „Option 4: Rack mounting - rear“
