The CHG 2W charging base

196

Meaning of the status LEDs on the charging

surfaces

The two blue status LEDs on the charging surfaces provide the

following status information:

Flashing normally: the device is charging

Flashing rapidly: excess temperature warning

Flashing/flickering very rapidly: unknown device on the char-

ger
