Sennheiser SpeechLine - Product overview and connections - rear panel

SL Rack Receiver DW
66
Product overview and connections – rear pan-
el
►
►
7 ANT I and ANT II antenna sockets (R-SMA)
• Antenna inputs for connecting the supplied rod antennae
• Alternatively, the antennae can be mounted using exten-
sion cables and the AWM 2 antenna wall mount or using
the GA 4 mounting kit.
• See „GA 4 mounting kit“ as well as „The AWM 2 antenna
wall mount“ and „The AWM 4 antenna wall mount“.
8 Strain relief grip
• For the cable of the power supply unit.
• See „Connecting the receiver to the power supply sys-
tem“.
9 DC IN socket
• For the power supply's hollow jack plug.
• See „Connecting the receiver to the power supply sys-
tem“.
10AF OUT UNBAL sockets (RCA)
• Unbalanced audio output.
• See „Connecting an amplifier or mixing console to the re-
ceiver“.
