Recommendations on antenna mounting

Option 3: Rack mounting - front

If you wish to install the antennae together with the receivers

in a rack, we recommend mounting the antennae on the front

side of the rack using the GA 4 mounting kit.

▷ Always leave 1 U of space between receivers and antennae.

▷ Position the antennas at an angle of about 45°.

►
