The SL Tablestand 153-S DW

147

Connecting the goose neck microphone

We recommend using the MEG 14-40-L-II goose neck micro-

phone. This microphone is optimally suited for the table stand.

To connect the goose neck microphone:

►

▷ Plug the goose neck microphone into the XLR-3 socket until

it locks into place.
