Recommendations on antenna mounting

▷ When using multiple AWM 2/AWM 4 antenna wall mounts,

make sure that the distances between all antennas are

equal:

►

▷ If possible, position the antennas so that there is a direct

line of sight (without obstacles) between the transmitters

and the antennas.

►
