SL Rack Receiver DW
83
5 6-step display for the RF signal level
• Displays the current level of the RF signal
6 RF output power of the transmitter, indicating master or fol-
lower
• Displays the RF output power of the received transmitter.
• Indicates whether the device is a master or a follower:
The device is the master.
The device is a follower.
The device is a follower, but is not synchronized.
The synchronization status is unknown.
7 Lock mode
•The lock mode function is activated. The lock
mode is currently deactivated and the receiver can
be operated.
•The lock mode function is activated. The lock
mode is currently activated. Long-press the jog
dial to temporarily deactivate the lock mode.
• If no padlock icon is displayed, the lock mode function is
deactivated.
• See „The System Settings menu“.
8 Name of the radio link
• The name of the radio link can be configured freely. See
„The Device Identification menu“.
9 Expected remaining battery life of the received transmitter
• Displays the remaining battery life of the received trans-
mitter in hours (only when the original Sennheiser BA 10,
BA 30 and BA 40 accupacks are used).
• The remaining battery life is not displayed when batteries
or rechargeable AA size batteries are used.
107-step display of the accupack or battery capacity
• Graphically displays the current charge status of the ac-
cupack or the batteries.
►
